MD80CTOR is a 31.5-inch 4K UHD touchscreen medical monitor designed for C-arm, fluoroscopy, interventional radiology and OR imaging workflows. With 3840×2160 resolution, DICOM-aligned display support, AG+AF protective glass, multi-I/O compatibility and a pedal-activated task light, it provides a large-format display option for image-guided procedures and medical imaging systems.
MD80CTOR is built for C-arm, fluoroscopy and interventional imaging systems that require a 31.5-inch 4K touchscreen display with DICOM-aligned image presentation. Its AG+AF protective glass, multi-signal inputs and pedal-activated task light support practical use in image-guided clinical and OR-adjacent environments.
MD80CTOR is positioned as a 31.5-inch 4K touchscreen medical monitor for C-arm, fluoroscopy, interventional radiology and OR imaging workflows. Its 3840×2160 resolution provides a large viewing area for image-guided procedures, while DICOM-aligned display support helps present X-ray and fluoroscopy images with more consistent grayscale behavior.
The monitor combines AG+AF protective glass, responsive touch operation, HDMI 2.0, DP 1.2, DVI and additional control interfaces for medical imaging system integration. Compared with FHD C-arm touch displays, MD80CTOR provides a larger 4K viewing format; compared with high-end diagnostic reading monitors, it is better positioned for C-arm and interventional imaging display rather than PACS or mammography diagnosis.
Buyer Fit
MD80CTOR is suitable for C-arm, fluoroscopy, interventional radiology, angiography and OR imaging systems that need a 31.5-inch 4K touchscreen medical display with DICOM-aligned image presentation, AG+AF protective glass, multi-signal input support and a pedal-activated task light.
| Product Type | 4K UHD Touch Medical Monitor |
|---|---|
| Screen Size | 31.5″ |
| Resolution | 3840 × 2160 (4K UHD) |
| Aspect Ratio | 16:9 |
| Brightness | 620 cd/m² |
| Contrast Ratio | 1000:1 |
| Color Depth | 10-bit (≈1.07B colors) |
| Viewing Angle | 178° H / 178° V |
| DICOM Compliance | DICOM calibration for fluoroscopy & X-ray imaging |
| Protective Glass | AG (Anti-Glare) + AF (Anti-Fingerprint) |
| Inputs | HDMI 2.0 ×2, DP 1.2 ×2, DVI ×1, USB ×1, DB-9 ×1, Touch ×1 |
| Outputs | HDMI 2.0 ×1, DVI ×1 |
| Power | DC 24V, 8.2A; 220W (max) |
| Dimensions | 755 × 479 × 71.9 mm (without stand) |
| Weight | 14.4 kg (without stand) |
| Mounting | VESA 100×100 mm / 200×200 mm |
| Application | C-arm, fluoroscopy and interventional imaging workflows |
Model Selection
MD80CTOR is positioned as a 31.5-inch 4K touchscreen medical monitor for C-arm, fluoroscopy and interventional imaging workflows. Use the comparison below to decide whether your system needs an FHD C-arm touch display, a larger 4K touch monitor, or a higher-resolution diagnostic monitor for multi-modality or mammography reading.
| Model | Size | Resolution | Main Positioning | Best For |
|---|---|---|---|---|
| MD20CTOR | 27" | 1920×1080 | FHD C-arm Touch | C-arm systems, fluoroscopy workflows and imaging setups that require FHD touch operation. |
| MD80CTOR | 31.5" | 3840×2160 | 4K C-arm / Interventional | C-arm, fluoroscopy, interventional radiology, angiography and OR imaging workflows that need a larger 4K touchscreen display. |
| MD85CA | 31.5" | 3840×2160 | 8MP Multi-Modality | PACS, CT, MRI, DR and mammography-related multi-modality diagnostic review. |
| MD120C | 31" | 4200×2800 | 12MP High-End Diagnostic | High-end mammography, multi-modality diagnostic reading and advanced radiology workstations. |
3840×2160 resolution provides a large and detailed viewing area for C-arm, fluoroscopy, interventional radiology and OR imaging workflows.
DICOM-aligned display support helps present X-ray, fluoroscopy and C-arm images with more consistent grayscale behavior during image-guided procedures.
Responsive touch operation supports image review, system interaction and workflow control in C-arm, fluoroscopy and interventional imaging environments.
AG+AF protective glass helps reduce glare, fingerprints and surface interference, supporting clearer viewing in OR imaging and interventional procedure environments.
The pedal-activated task light provides a visible workflow signal during imaging operation, helping teams coordinate image capture and procedure steps.
HDMI 2.0, DP 1.2, DVI, USB, DB-9 and touch interfaces support integration with C-arm, fluoroscopy and medical imaging system configurations.
MD80CTOR supports C-arm fluoroscopy workflows where a 31.5-inch 4K touchscreen display is required for X-ray image review and image-guided procedure support.
With 4K resolution, touch operation and DICOM-aligned display support, MD80CTOR is suitable for interventional radiology environments that require clear image presentation and system interaction.
MD80CTOR can support cardiovascular angiography and interventional imaging workflows where 4K image presentation, AG+AF protective glass and multi-I/O compatibility are required.
MD80CTOR provides a 31.5-inch 4K touchscreen display format for C-arm, fluoroscopy, interventional radiology and OR imaging workflows.
DICOM-aligned display support helps present X-ray, C-arm and fluoroscopy images with more consistent grayscale behavior in medical imaging environments.
HDMI 2.0, DP 1.2, DVI, USB, DB-9 and touch interfaces help connect MD80CTOR with C-arm, fluoroscopy and interventional imaging system configurations.
AG+AF protective glass helps reduce glare, fingerprints and viewing interference during image-guided procedures and OR imaging use.
Responsive touch operation and the pedal-activated task light support practical workflow interaction during C-arm, fluoroscopy and interventional imaging procedures.
For C-arm, fluoroscopy or interventional imaging projects, Reshin can provide the MD80CTOR datasheet and help confirm whether this 4K touchscreen model fits the intended system requirement.
Share your imaging system type, required resolution, input interface, mounting method and expected quantity. Reshin will help confirm whether MD80CTOR is suitable or recommend another C-arm, fluoroscopy or diagnostic monitor model if needed.
