19-inch medical diagnostic display with 1MP grayscale, 600 cd/m² brightness, DICOM Part 14 calibration, ensuring stable imaging for CT, MRI, C-ARM, PACS workstations.
High-precision grayscale diagnostic monitor with DICOM calibration and CBS brightness stabilization, ensuring consistent clarity for clinical review.
MD18G is a 19-inch medical diagnostic display designed for precise grayscale imaging in clinical environments. Featuring 1MP resolution at 1280×1024, 600 cd/m² brightness, and 12-bit grayscale depth, it ensures clear and accurate visualization for CT, MRI, C-ARM, and DSA applications. The monitor supports DICOM Part 14 calibration with multiple gamma modes, enabling faithful grayscale GSDF display across diverse modalities. Its CBS luminance stabilization system guarantees long-term image consistency, reducing visual fatigue and enhancing diagnostic confidence. With versatile input options including VGA, DP, DVI, HDMI, and BNC, the display integrates seamlessly into PACS workstations and hospital networks. Built with a durable black metal housing, the MD18G combines reliability, compliance, and clinical efficiency, making it a trusted solution for acquisition and review of medical images in modern healthcare settings.
| Product Type | Medical Diagnostic Display |
|---|---|
| Screen Size | 19″ (48.26 cm) |
| Resolution | 1280 × 1024 (1MP) |
| Aspect Ratio | 5:4 |
| Brightness | 600 cd/m² (default) |
| Contrast Ratio | 1200:1 |
| Grayscale Depth | 12-bit |
| Viewing Angle | 178° H / 178° V |
| Gamma / DICOM Modes | Multiple DICOM curves & Gamma modes |
| Response Time | 14 ms (TYP) |
| Stabilization | CBS Luminance Stabilization |
| Inputs | VGA, DP, DVI, HDMI, BNC, USB |
| Power | AC 110–240V, 30W (MAX) |
| Dimensions (W×H×D) | 421 × 364.5 × 66.8 mm (without stand) |
| Weight | 4.5 kg (without stand) / 5.9 kg (with stand) |
| Mounting | VESA 100 × 100 mm |
| Chassis | Black metal shell |
600 cd/m² luminance and 1200:1 contrast ensure sharp, high-visibility images. This 1MP grayscale diagnostic display supports consistent performance in hospital PACS workstations and provides reliable clarity for CT, MRI, C-ARM, and DSA applications.
With 12-bit grayscale depth, the display captures subtle density variations, enhancing GSDF accuracy. Clinicians benefit from improved lesion detection and reliable grayscale rendering across CT, MRI, and fluoroscopy imaging workflows.
Factory DICOM calibration and multiple gamma modes guarantee grayscale conformity. The 19-inch medical diagnostic display delivers accurate reproduction for DR, CR, and CT/MRI acquisition, supporting daily diagnostic and clinical review tasks.
The CBS brightness stabilization system compensates for luminance drift, ensuring long-term stability. It maintains consistent image quality, critical for diagnostic reproducibility and confidence in PACS workstations and grayscale GSDF display standards.
Equipped with VGA, DP, DVI, HDMI, and BNC inputs, this medical diagnostic display ensures broad system compatibility. Full-format connectivity minimizes analog interference, supporting seamless integration with PACS, CT/MRI consoles, and clinical imaging setups.
A wide 178° viewing angle delivers consistent image clarity from any position. VESA 100×100 mounting and ergonomic design support easy installation, making the 19-inch DICOM grayscale monitor reliable for busy hospital environments.
Optimized grayscale accuracy and DICOM Part 14 calibration ensure clear visualization of CT scans, helping clinicians make confident decisions with this 19-inch medical diagnostic display.
Precise 12-bit grayscale reproduction enhances subtle contrasts in MRI scans. The stable CBS luminance stabilization system ensures reliable results across neurological and clinical assessments.
Seamless integration with PACS workstation setups via VGA, DP, DVI, HDMI, and BNC inputs supports accurate review of CT, MRI, and X-ray images on a grayscale GSDF display.
Each MD18G ships with verified DICOM Part 14 calibration, delivering precise grayscale performance for CT, MRI, and PACS diagnostic applications.
CBS brightness stabilization compensates luminance drift, ensuring uniform grayscale output and stable long-term diagnostic accuracy in hospital environments.
Equipped with VGA, DP, DVI, HDMI, and BNC inputs, the MD18G integrates smoothly into PACS workstation setups for reliable grayscale imaging.
Compliant with ISO 13485 and CE-MDR standards, this 19-inch medical diagnostic display ensures global safety, quality, and clinical reliability.
The MD18G includes a 5-year warranty, responsive global service, and long-term parts availability to support hospital diagnostic workflows.
OEM/ODM flexibility and VESA 100×100 mounting allow easy adaptation to PACS, CT/MRI consoles, and varied clinical environments.
