1920×1200 WUXGA CT/MRI image reading display with 10-bit color, DICOM-QC auto calibration, uniform brightness compensation for DR, CT, MRI, and PACS.
Reliable 1920×1200 WUXGA medical display for DR, CT, MRI, and PACS acquisition, ensuring consistent clarity, ergonomic design, and dependable clinical performance.
The MD26C is a 24-inch 2.3MP clinical display built for reliable CT/MRI image reading and PACS acquisition workstations. Featuring 1920×1200 WUXGA resolution with 10-bit color depth, it ensures precise grayscale and color imaging for DR, CT, and MRI applications. Equipped with DICOM-QC auto calibration and uniform brightness compensation, this WUXGA medical LCD maintains consistent clarity across the screen. Sixteen gamma presets offer flexible adaptation to different diagnostic modalities, while the one-touch film viewer lightbox mode provides quick high-brightness display for X-ray film comparison. Designed as an ergonomic imaging acquisition workstation monitor, the MD26C combines dependable performance, versatile DP/DVI/VGA connectivity, and workflow-oriented functions, making it a practical choice for daily radiology environments.
| Product Type | Color Diagnostic Display (Clinical Review) |
|---|---|
| Screen Size | 24″ (60.96 cm) |
| Resolution | 1920 × 1200 (WUXGA · 2.3MP) |
| Pixel Pitch (H × V) | 0.270 × 0.270 mm |
| Aspect Ratio | 16:10 |
| Color Depth | 10-bit, approx. 1.07 billion colors |
| Luminance (Default) | 350 cd/m² |
| Contrast Ratio | 1000:1 |
| Viewing Angle | 178° H / 178° V |
| Gamma / DICOM Presets | 16 presets: DICOM250/300/350/400/450, CT(MRI), DSA, CR/DR, CRT, DSI, GAMMA 1.8/2.0/2.2/2.4, LINEAR |
| Inputs | DP ×1, DVI-D ×1, VGA ×1 |
| Power | DC 24V 5A; 60W (Max) |
| Dimensions (W × H × D) | 568.25 × 392.3 × 64.1 mm (without stand) |
Automatic curve detection and adjustment ensure compliance with DICOM Part 14, making this CT/MRI image reading display accurate for clinical review.
Advanced compensation reduces luminance non-uniformity, keeping the 1920×1200 WUXGA medical monitor consistent for DR, CT, MRI, and PACS workflows.
Sixteen presets, including DICOM250–450, CR/DR, CT(MRI), and Gamma 1.8–2.4, allow this 2.3MP clinical display to adapt flexibly across imaging modalities.
A dedicated mode provides instant high-brightness for X-ray film comparison, positioning the monitor as a film viewer one-touch lightbox clinical monitor.
Fast switching between color and grayscale supports both general clinical tasks and precise grayscale imaging, ideal for an ergonomic image acquisition monitor.
Featuring 10-bit depth (~1.07B colors) with DP, DVI-D, and VGA inputs, this DP DVI VGA medical display ensures reliable PACS acquisition workstation connectivity.
24″ 1920×1200 WUXGA medical monitor with DICOM-QC and uniform brightness compensation ensures stable images for PACS acquisition and daily review.
10-bit color depth with 16 gamma/DICOM presets highlights subtle contrasts, making this 2.3MP clinical display reliable for CT and MRI imaging tasks.
One-touch high-brightness lightbox with DICOM-compliant grayscale supports accurate chest and skeletal X-ray comparison in routine radiology workflows.
Each 24″ 1920×1200 WUXGA medical monitor ships with DICOM-QC verification, ensuring consistent grayscale accuracy for CT/MRI image reading and PACS acquisition.
Closed-loop brightness compensation maintains uniform luminance across the 2.3MP clinical display, delivering reliable image quality for DR, CT, and MRI applications.
Broad DP, DVI, and VGA connectivity ensures smooth integration with PACS acquisition workstations, CT/MRI consoles, and routine clinical imaging setups.
Manufactured under ISO 13485 and CE-MDR standards, this ergonomic image acquisition monitor meets strict quality and safety requirements for global medical markets.
Comprehensive support with rapid response, 5-year warranty, and long-term parts availability ensures dependable use in radiology and clinical workstation workflows.
Flexible OEM/ODM options adapt settings for DR, CT, and MRI modalities, while one-touch film viewer lightbox mode enhances X-ray comparison efficiency.
