A 21.3-inch 2MP radiology diagnostic monitor (1600×1200, 12-bit, DICOM Part 14, CBS) integrates smoothly with PACS workstations, reducing early QC and training overhead while increasing delivery certainty.
The 21.3-inch 2MP radiology diagnostic monitor with CBS luminance stabilization, lightbox mode and auto rotation shortens reading turnaround and reduces rework
The MD26GA is a 21.3-inch 2MP radiology diagnostic monitor for DR/CR, designed to deliver precise and consistent imaging across DR, CR, CT, MRI, and PACS diagnostic workstation applications. Featuring a 1600×1200 grayscale IPS diagnostic display with 12-bit grayscale depth and full DICOM Part 14 GSDF compliance, it ensures accurate visualization of medical images. Advanced CBS luminance stabilization and ambient light compensation maintain long-term brightness uniformity and reduce eye strain, while the one-touch lightbox mode and automatic portrait/landscape rotation streamline clinical workflows. With versatile HDMI, DP, DVI, and VGA medical display connectivity, the MD26GA integrates seamlessly into modern radiology environments, providing a reliable and efficient 2MP diagnostic solution for professional use.
| Product Type | Diagnostic Monitor (DICOM-Compliant) |
|---|---|
| Screen Size | 21.3″ |
| Resolution | 1600 × 1200 (2MP) |
| Aspect Ratio | 4:3 |
| Grayscale Depth | 12-bit |
| Brightness | 400 cd/m² (default) |
| Contrast Ratio | 1800:1 |
| Viewing Angle | 178° H / 178° V |
| Gamma / DICOM Modes | DICOM350–600, LINEAR, CRT, DSA, DSI, CT/MRI, RX1/RX2, GAMMA 1.8/2.0/2.2/2.4 |
| Stabilization | CBS Luminance Stabilization |
| Calibration | DICOM-QC Auto Calibration (±5% deviation) |
| Inputs | VGA, DP, DVI-D, HDMI, BNC (SOG compatible), USB |
| Power | DC 24V 5A, 50W (max) |
DICOM-QC auto calibration (±5%) keeps the 2MP radiology diagnostic monitor compliant with DICOM Part 14, cutting manual QC and rework.
CBS luminance stabilization controls luminance drift, lowering disputes and service frequency in long-term PACS workstation use.
1600×1200 with 12-bit sustains diagnostic detail, reducing second opinions and delays caused by missed info.
Lightbox mode offers one-touch white screens, removing external lightboxes and reducing ad-hoc device and safety risks.
Auto rotation (built-in G-sensor) cuts UI adjustment time, speeding report turnaround.
HDMI/DP/DVI-D/VGA/BNC + 21.3″ 4:3 ergonomics provide compatibility and refresh certainty, reducing retrofit and training costs.
The 2MP radiology diagnostic monitor (DICOM grayscale) reduces DR misreads, cutting callbacks and back-and-forth.
12-bit grayscale with stable luminance supports CR detail review, reducing delays from repeated confirmations.
DICOM GSDF + 2MP 21.3 inch highlights subtle MRI contrasts, reducing repeated confirmations in MDT.
Factory DICOM calibration (DICOM GSDF) makes the MD26GA 2MP radiology diagnostic monitor ready to use, reducing early QC manpower.
Closed-loop CBS luminance stabilization keeps luminance uniform, lowering inter-department disputes and rework.
Multi-format I/O (HDMI/DP/DVI-D/VGA/BNC) shortens integration cycles, reducing downtime windows and hidden costs.
ISO 13485 / CE-MDR reduces compliance/audit risk at the source, facilitating multi-region approvals and acceptance.
24-hour response + 5-year warranty + spare parts ensure lifecycle availability, reducing downtime opportunity cost.
Flexible OEM/ODM fits DR/CR/CT/MRI; lightbox mode improves film comparison efficiency, reducing training friction.
