27-inch FHD C-arm touch medical monitor with DICOM calibration, AG/AF glass, multi-interface, and foot pedal-activated overhead light for surgical fluoroscopy imaging.
27-inch 1920x1080 medical touch display for surgical C-arm, featuring DICOM compliance, dynamic task lighting, AG/AF coating, and 24V design for fluoroscopy imaging.
The MD20CTOR is a 27-inch FHD C-arm touch medical monitor purpose-built for surgical fluoroscopy applications. With 1920×1080 resolution, 620 cd/m² brightness, and DICOM calibration, it ensures accurate grayscale rendering for X-ray and fluoroscopy imaging. This touchscreen medical monitor for surgical C-arm features a responsive interface that improves workflow efficiency, while AG/AF protective glass reduces glare and fingerprints for clear, uninterrupted visuals. Equipped with versatile connectivity including DVI, VGA, and USB, the 24V medical touch display integrates seamlessly across operating room systems. Its dynamic task lighting design includes a foot pedal-activated overhead light monitor, providing visual confirmation during imaging procedures. Engineered as a surgical fluoroscopy display and OR touch monitor, the MD20CTOR combines clarity, intuitive control, and robust reliability. It is an ideal solution for hospitals seeking a DVI VGA multi-interface C-arm monitor that supports accurate diagnostics and efficient operation in advanced surgical environments.
| Product Type | Touch Screen Medical Monitor (DICOM-compliant) |
|---|---|
| Screen Size | 27″ |
| Resolution | 1920 × 1080 (FHD) |
| Brightness (Default) | 620 cd/m² |
| Contrast Ratio | 1000:1 |
| Color Depth | Approx. 1.07 billion colors |
| Viewing Angle | 178° H / 178° V |
| Gamma / DICOM Modes | LINEAR, Gamma 1.8 / 2.0 / 2.2 / 2.4 / 2.6, DICOM, CUSTOMER 1–4 |
| Front Glass & Coating | AG anti-glare protective glass; AF anti-fingerprint treatment |
| Interfaces (I/O) | DVI In ×1, VGA ×1, USB ×1, Fluorolamp connector (D-Sub 9, female) ×1; DVI Out ×1 |
| Power | DC 24V 5A; 80W (max) |
| Dimensions (W × H × D) | 647 × 419 × 59.9 mm (without stand) |
| Mounting | VESA 100 × 100 mm, VESA 200 × 200 mm |
27-inch 1920×1080 medical touch display with 620 cd/m² brightness ensures sharp, reliable images for C-arm imaging and surgical fluoroscopy display environments.
High-sensitivity interface makes this FHD C-arm touch medical monitor ideal for fast workflow adjustments and intuitive operation in surgical imaging procedures.
As a DICOM-compliant radiology display, it ensures precise grayscale rendering for fluoroscopy imaging, supporting accuracy and consistency across surgical C-arm workflows.
Equipped with anti-glare and anti-fingerprint protection, this 27-inch medical touch display reduces reflections and smudges, delivering uninterrupted clarity in operating rooms.
Dynamic task lighting touch medical screen with integrated pedal-activated overhead light improves usability, offering clear workflow signals during complex procedures.
DVI, VGA, and USB ports with 24V medical touch display compatibility ensure seamless integration with C-arm monitors, PACS systems, and OR touch monitor setups
FHD C-arm touch medical monitor with DICOM calibration and responsive operation ensures real-time fluoroscopy workflows and accurate grayscale rendering in the OR.
27 inch 1920x1080 medical touch display with AG/AF coating and stable brightness delivers crisp contrast for fluoroscopy imaging and angiography surgical procedures.
DVI VGA multi-interface C-arm monitor with USB and foot pedal-activated overhead light supports seamless integration and efficiency in surgical fluoroscopy display setups.
27-inch 1920×1080 medical touch display with 620 cd/m² brightness ensures sharp, reliable images for C-arm imaging and surgical fluoroscopy display environments.
High-sensitivity interface makes this FHD C-arm touch medical monitor ideal for fast workflow adjustments and intuitive operation in surgical imaging procedures.
As a DICOM-compliant radiology display, it ensures precise grayscale rendering for fluoroscopy imaging, supporting accuracy and consistency across surgical C-arm workflows.
Equipped with anti-glare and anti-fingerprint protection, this 27-inch medical touch display reduces reflections and smudges, delivering uninterrupted clarity in operating rooms.
Dynamic task lighting touch medical screen with integrated pedal-activated overhead light improves usability, offering clear workflow signals during complex procedures.
DVI, VGA, and USB ports with 24V medical touch display compatibility ensure seamless integration with C-arm monitors, PACS systems, and OR touch monitor setups.
